CASE PSU ATX3.1 1000W/GP-UD1000GM PG5 V2 GIGABYTE
ELKO kood
1446274
Ensure reliable and efficient power delivery with GIGABYTE power supplies. Designed for peak performance and durability, our PSUs offer stable and consistent energy to power your high-performance systems. With advanced protections and high-quality components, GIGABYTE power supplies provide the confidence you need for seamless, uninterrupted computing experiences.
Spetsifikatsioon
MasterImage
https://static.elko.cloud/ProductImages/4830041c-2bfb-46b5-a469-f529d5e23180.Jpeg
CnCode
85044095
Unit Calculated Weight
2.7
Unit Calculated Volume
0.007812
Shipping Box Width
22.5
Shipping Box Depth
62
Shipping Box Height
28
Shipping Box Weight
13.5
Units per Shipping Box
5
Units per Pallet
0
Model name
GP-UD1000GM
Warranty period
10
Package type
Box
Package weight
2640
Package width
618
Package depth
269
Package height
211
Width
150
Depth
140
Height
86
Weight
2480
Number of fans
1
Product colour
Black
Cooling type
Active
Fan diameter
120
On/off switch
Y
80 PLUS certification
80 PLUS Gold
Purpose
PC
Power supply unit (PSU) form factor
ATX
ATX version
3.1
Bearing technology
HYB
Mean time between failures (MTBF)
100000
Number of EPS connectors
2
PCI Express power connectors (16-pin)
1
CPU power cable length
600
Floppy drive power connector
1
Cabling type
Fully-Modular
CPU power connector (4+4 pin)
Y
PCI Express connector
Y
Motherboard power connector
20+4 pin ATX
Number of SATA power connectors
8
Peripheral (Molex) power connectors (4-pin)
3
PCI Express power connectors (6+2 pin)
4
Motherboard power cable length
610
SATA power cable length
150
SATA power cable length
600
Peripheral (Molex) power cable length
150
Peripheral (Molex) power cable length
500
Peripheral (Molex) power cable length
120
PCI Express power cable length
700
Power factor
0.9
Power Factor Correction (PFC) type
Active
Hold time
16
Power protection features
Over current
Power protection features
Over power
Power protection features
Over voltage
Power protection features
Overheating
Power protection features
Short circuit
Power protection features
Under voltage
Input current
15 - 6.5
Max output current (+3.3V)
25
Max output current (+12V)
83.3
Max output current (+5V)
25
Max output current (-12V)
0.3
Max output current (+5Vsb)
3
AC input voltage
100 - 240
Total power
1000
Combined power (+3.3V)
125
Combined power (+12V)
1000
Combined power (+5V)
125
Combined power (-12V)
3.6
Combined power (+5Vsb)
15
AC input frequency
50/60
Efficiency
90
