MB B860 S1851 MATX/TUF GAMING B860M-PLUS ASUS
ELKO kood
1433006
TUF GAMING
B860M-PLUS
ASUS TUF GAMING B860M-PLUS takes all the essential elements of the latest Intel® Core™ Ultra Processors (Series 2) and combines them with game-ready features and proven durability. Engineered with military-grade components, an upgraded power solution and a comprehensive cooling system, this motherboard goes beyond expectations with rock-solid and stable performance for marathon gaming. TUF GAMING motherboards also undergo rigorous endurance testing to ensure that they can handle conditions where others may fail. This platform delivers the power and connectivity that advanced AI PC applications demand.
B860M-PLUS
ASUS TUF GAMING B860M-PLUS takes all the essential elements of the latest Intel® Core™ Ultra Processors (Series 2) and combines them with game-ready features and proven durability. Engineered with military-grade components, an upgraded power solution and a comprehensive cooling system, this motherboard goes beyond expectations with rock-solid and stable performance for marathon gaming. TUF GAMING motherboards also undergo rigorous endurance testing to ensure that they can handle conditions where others may fail. This platform delivers the power and connectivity that advanced AI PC applications demand.
Spetsifikatsioon
MasterImage
https://static.elko.cloud/ProductImages/a67170f0-cafc-4953-85bc-9b53823fe9e8.Jpeg
CnCode
84733020
Unit Calculated Weight
1.7
Unit Calculated Volume
0.006234
Shipping Box Weight
17
Shipping Box Width
36.7
Shipping Box Depth
57
Shipping Box Height
29.8
Units per Shipping Box
10
Screws included
Y
Cables included
SATA
Width
244
Depth
244
Package width
275
Package depth
275
Package height
67.5
Package weight
1652
SATA
Yes
USB-C
Yes
HDMI
1
USB 2.0
Yes
USB 3.0
4
BIOS type
UEFI AMI
BIOS memory size
256
DisplayPort
1
USB 3.2
Yes
3rd M.2 highest PCI Express generation
4.0
PCI Express x4 (Gen 4.x) slots
1
PCI Express x16 (Gen 5.x) slots
1
1st M.2 largest key size
2280
1st M.2 highest PCI Express generation
5.0
2nd M.2 largest key size
2280
2nd M.2 highest PCI Express generation
4.0
Number of M.2 (M) slots
3
Bluetooth
Yes
WiFi
Yes
Wi-Fi
N
Ethernet interface type
2.5 Gigabit Ethernet
Ethernet LAN
Y
S/PDIF out port
Y
USB 2.0 ports quantity
1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
4
Ethernet LAN (RJ-45) ports
1
DisplayPorts quantity
1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity
2
HDMI ports quantity
1
USB 3.2 Gen 2x2 Type-C ports quantity
1
USB 3.2 Gen 2 (3.1 Gen 2) connectors
1
Thunderbolt headers
1
Number of chassis fan connectors
3
USB 2.0 connectors
1
USB 3.2 Gen 1 (3.1 Gen 1) connectors
1
Number of SATA III connectors
4
Front panel connector
Y
12V power connector
Y
Front panel audio connector
Y
ATX Power connector (24-pin)
Y
CPU fan connector
Y
Chassis intrusion connector
Y
Parallel processing technology support
Not supported
RAID support
Y
Supported storage drive interfaces
M.2,SATA III
RAID levels
0
RAID levels
1
RAID levels
5
RAID levels
10
Number of HDDs supported
4
Number of storage drives supported
7
Supported storage drive types
HDD & SSD
Memory channels
Dual-channel
Supported memory types
DDR5-SDRAM
Number of memory slots
4
Memory slots type
DIMM
ECC ?ompatibility
non-ECC
Unbuffered memory
Y
PCI-Express 4.0 4x
1
Maximum internal memory
256
Processor manufacturer
Intel
Processor socket
LGA 1851 (Socket V1)
Compatible processor series
Intel Core Ultra (Series 2)
Supported processor sockets
LGA 1851
PCI-Express 5.0 16x
1
USB 2.0
1
M.2
3
SATA 3.0
Yes
USB 3.2
2
USB-C
2
Motherboard chipset
Intel B860
Component for
PC
Motherboard form factor
Micro ATX
Motherboard chipset family
Intel
Windows operating systems supported
Windows 10 x64
Windows operating systems supported
Windows 11
Audio output channels
7.1
Optical S/PDIF
1
RJ45
1
Audio port
5
Model
TUF GAMING B860M-PLUS
