CASE PSU ATX 650W/SSR-650FM SEASONIC
ELKO kood
1427545
The G12 GM Series is available in the standard ATX Form Factor and in wattages that are most common for a PC system. The Seasonic G12 GM-Series achieves 80 PLUS® Gold standard of providing at least 87 %, 90 % and 87 % power usage efficiency at 20 %, 50 % and 100 % operating loads, respectively. This efficiency, combined with Active Power Factor Correction, enables the G12 GM series power supplies to lessen energy waste, which translates into savings on the costs of energy costs for its users. In addition to being greatly efficient, the G12 GM units utilize the LLC resonant converter design, and the industry’s leading Smart and Silent Fan Control (S2FC).
80 PLUS GOLD
The G12 GC achieves 80 PLUS Gold certification with its 90 % efficiency at 50 % system load.
S2FC - SMART AND SILENT FAN CONTROL
The intelligent thermal circuit feature is designed to find the optimal balance between the necessity to cool the components and the need to run the power supply in the most silent manner possible.
80 PLUS GOLD
The G12 GC achieves 80 PLUS Gold certification with its 90 % efficiency at 50 % system load.
S2FC - SMART AND SILENT FAN CONTROL
The intelligent thermal circuit feature is designed to find the optimal balance between the necessity to cool the components and the need to run the power supply in the most silent manner possible.
Spetsifikatsioon
MasterImage
https://static.elko.cloud/ProductImages/8d9c8f30-6d9e-4c52-9fa5-c301b3f8864b.Jpeg
CnCode
85044095
Unit Calculated Weight
2.52
Unit Calculated Volume
0.0060088
Shipping Box Width
11.5
Shipping Box Depth
27.5
Shipping Box Height
19
Shipping Box Weight
2.52
Units per Shipping Box
1
Model name
G12 GM-650
Warranty period
5
Package type
Box
Height
86
Width
150
Depth
140
Compliance certificates
RoHS
Compliance certificates
CE
Cables included
AC,PCIe,Peripheral (Molex),SATA
Cable tie(s) included
Y
Operating temperature (T-T)
0 - 50
Cooling type
Active
On/off switch
Y
Product colour
Black
Fan diameter
120
Number of fans
1
Bearing technology
Sleeve
80 PLUS certification
80 PLUS Gold
Purpose
PC
Power supply unit (PSU) form factor
ATX
Mean time between failures (MTBF)
100000
Motherboard power connector
20+4 pin ATX
Number of SATA power connectors
6
Peripheral (Molex) power connectors (4-pin)
3
PCI Express power connectors (6+2 pin)
2
Cabling type
Semi-Modular
Motherboard power cable length
550
Peripheral (Molex) power cable length
690
PCI Express power cable length
700
Total power
650
AC input voltage
100 - 240
AC input frequency
50/60
Input current
10
Combined power (+3.3V)
100
Combined power (+12V)
648
Combined power (+5V)
100
Combined power (-12V)
3.6
Combined power (+5Vsb)
12.5
Max output current (+3.3V)
20
Max output current (+12V)
45
Max output current (+5V)
20
Max output current (-12V)
3.6
Max output current (+5Vsb)
2.5
Power protection features
Over current
Power protection features
Over voltage
Power protection features
Short circuit
