CASE PSU ATX3.0 650W/GP-P650SS ICE GIGABYTE
ELKO kood
1426129
Ensure reliable and efficient power delivery with GIGABYTE power supplies. Designed for peak performance and durability, our PSUs offer stable and consistent energy to power your high-performance systems. With advanced protections and high-quality components, GIGABYTE power supplies provide the confidence you need for seamless, uninterrupted computing experiences.
Spetsifikatsioon
MasterImage
https://static.elko.cloud/ProductImages/bbf0034a-f4c5-42c0-b5fe-a5b611a027d3.Jpeg
CnCode
85044095
Unit Calculated Weight
2.26
Unit Calculated Volume
0.007638
Shipping Box Width
22
Shipping Box Depth
62
Shipping Box Height
28
Shipping Box Weight
11.3
Units per Shipping Box
5
Model name
GP-P650SS ICE
Warranty period
3
Package width
254
Package depth
206
Package height
117
Package weight
2600
Package type
Box
Width
140
Depth
150
Height
86
Weight
2230
On/off switch
Y
Cooling type
Active
Product colour
White
Fan diameter
120
Number of fans
1
Fan location
Top
80 PLUS certification
80 PLUS Silver
Purpose
PC
Power supply unit (PSU) form factor
ATX
ATX version
3.0
Mean time between failures (MTBF)
100000
Bearing technology
FDB
CPU P4 connector (4-pin)
1
Motherboard power cable length
600
SATA power cable length
500
SATA power cable length
120
Peripheral (Molex) power cable length
500
Peripheral (Molex) power cable length
120
PCI Express power cable length
650
CPU power cable length
600
Floppy disk drive connector
Y
Motherboard power connector
20+4 pin ATX
Number of SATA power connectors
5
Peripheral (Molex) power connectors (4-pin)
2
PCI Express power connectors (6+2 pin)
2
CPU power connector (4+4 pin)
Y
ATX power connector (20+4 pin)
Y
Cabling type
Non-Modular
Total power
650
AC input voltage
155-240
AC input frequency
50/60
Input current
6.3
Power factor
0.9
Power Factor Correction (PFC) type
Active
Combined power (+3.3V)
100
Combined power (+12V)
649.2
Combined power (+5V)
100
Combined power (-12V)
3.6
Combined power (+5Vsb)
15
Max output current (+3.3V)
20
Max output current (+12V)
54.1
Max output current (+5V)
20
Max output current (-12V)
0.3
Max output current (+5Vsb)
3
Power protection features
Over power
Power protection features
Short circuit
Power protection features
Under voltage
Power protection features
Overcharge
Power Good signal delay range
100 - 150
