CASE PSU ATX 700W/TPS-700S CHIEFTEC
ELKO kood
1339188
TPS-700S
The CHIEFTEC Task Series PSU’s are true to their name, and take on any task they are required for without any trouble. With certified 80PLUS Bronze efficiency and all modern protection and safety features, the PSU can be trusted to deliver power efficiently and reliably. With cable lengths extended to 650mm for motherboard and CPU, these power supplies will also serve excellently for builds inside larger cases.
The CHIEFTEC Task Series PSU’s are true to their name, and take on any task they are required for without any trouble. With certified 80PLUS Bronze efficiency and all modern protection and safety features, the PSU can be trusted to deliver power efficiently and reliably. With cable lengths extended to 650mm for motherboard and CPU, these power supplies will also serve excellently for builds inside larger cases.
Spetsifikatsioon
MasterImage
https://static.elko.cloud/ProductImages/bb781ab0-7571-4be6-a1fc-cccc6a17f8f8.Jpeg
CnCode
85044095
Unit Calculated Weight
2.07
Unit Calculated Volume
0.0045649
Shipping Box Depth
23.5
Shipping Box Height
18.5
Shipping Box Weight
2.07
Shipping Box Width
10.5
Units per Shipping Box
1
EPS cable length
650
Harmonized System (HS) code
84733020
Package weight
2150
Package type
Box
Width
150
Depth
140
Height
87
Weight
1740
Certification
ErP, CE, CB, EAC, TUV
Compliance certificates
RoHS
Product colour
Black
Fan diameter
120
Number of fans
1
80 PLUS certification
80 PLUS Bronze
Purpose
PC
Power supply unit (PSU) form factor
ATX
Supported motherboard form factors
ATX
Motherboard power cable length
650
SATA power cable length
150
SATA power cable length
500
Peripheral (Molex) power cable length
150
Peripheral (Molex) power cable length
500
PCI Express power cable length
500
EPS power connector (4+4 pin)
Y
Motherboard power connector
20+4 pin ATX
Number of SATA power connectors
6
Peripheral (Molex) power connectors (4-pin)
3
PCI Express power connectors (6+2 pin)
2
ATX power connector (20+4 pin)
Y
Cabling type
Non-Modular
Total power
700
AC input voltage
100 - 240
AC input frequency
47 - 63
Input current
10
Power factor
0.9
Power Factor Correction (PFC) type
Active
Combined power (+12V)
648
Combined power (-12V)
3.6
Combined power (+5Vsb)
12.5
Max output current (+3.3V)
19
Max output current (+12V)
54
Max output current (+5V)
17
Max output current (-12V)
0.3
Max output current (+5Vsb)
2.5
Power protection features
Over voltage
Power protection features
Overheating
Power protection features
Short circuit
Power protection features
Under voltage
Power protection features
Overload
