CASE PSU ATX2.31 450W/GP-P450B GIGABYTE
ELKO kood
1305336
80 PLUS BRONZE CERTIFIED
80 Plus Bronze certified ensures to deliver 85% efficiency at 50% load. The better power efficiency leads to less power waste, less heat and less fan noise.
Reliable Flat Cable
P450B provides the best solution for the system builds. The flat cable reduces the clutter and improves the airflow in the case.
120mm Silent Hydraulic Bearing (HYB) Fan
120mm Silent Hydraulic Bearing fan optimizes the noise reduction and the thermal performance. The fan speed is adjusted according to the automatic power detection. The Hydraulic Bearing fan provides longer and more stable life time.
SINGLE +12V RAIL
Single +12V rail provides the best power output, stability and compatibility for the hardware. It provides the easiest way to install the power cable. And it is the best design for overclocking.
PROTECTION
In order to make sure the entire computer system to operate stably under any conditions, we not only added protection designs such as OCP, OTP, OVP, OPP, UVP and SCP, but also ensured the stable operation of your system through the safety certification of various countries.
80 Plus Bronze certified ensures to deliver 85% efficiency at 50% load. The better power efficiency leads to less power waste, less heat and less fan noise.
Reliable Flat Cable
P450B provides the best solution for the system builds. The flat cable reduces the clutter and improves the airflow in the case.
120mm Silent Hydraulic Bearing (HYB) Fan
120mm Silent Hydraulic Bearing fan optimizes the noise reduction and the thermal performance. The fan speed is adjusted according to the automatic power detection. The Hydraulic Bearing fan provides longer and more stable life time.
SINGLE +12V RAIL
Single +12V rail provides the best power output, stability and compatibility for the hardware. It provides the easiest way to install the power cable. And it is the best design for overclocking.
PROTECTION
In order to make sure the entire computer system to operate stably under any conditions, we not only added protection designs such as OCP, OTP, OVP, OPP, UVP and SCP, but also ensured the stable operation of your system through the safety certification of various countries.
Spetsifikatsioon
MasterImage
https://static.elko.cloud/ProductImages/ef7f0bb8-0a28-44ca-bf59-32eba8b25b12.Jpeg
CnCode
85044095
Unit Calculated Weight
2.09
Unit Calculated Volume
0.008395
Shipping Box Width
53.1
Shipping Box Height
25.5
Shipping Box Weight
20.95
Shipping Box Depth
62
Units per Shipping Box
10
Model name
P450B
Harmonized System (HS) code
84733020
Width
150
Depth
140
Height
86
Product colour
Black
Fan diameter
120
Number of fans
1
Fan location
Top
Cooling type
Active
On/off switch
Y
Bearing technology
HDB
80 PLUS certification
80 PLUS Bronze
Purpose
PC
Power supply unit (PSU) form factor
ATX
ATX version
2.31
Mean time between failures (MTBF)
100000
ATX power connector (20+4 pin)
Y
Floppy drive power connector
1
Cabling type
Non-Modular
Motherboard power connector
20+4 pin ATX
Number of SATA power connectors
6
Peripheral (Molex) power connectors (4-pin)
3
PCI Express power connectors (6+2 pin)
2
CPU power connector (4+4 pin)
Y
CPU power cable length
600
PCI Express connector
Y
Motherboard power cable length
550
SATA power cable length
500
Peripheral (Molex) power cable length
500
PCI Express power cable length
550
Floppy disk drive connector
Y
Total power
450
AC input voltage
100 - 240
AC input frequency
50 - 60
Input current
8 - 4
Power factor
0.9
Power Factor Correction (PFC) type
Active
Combined power (+3.3V)
103
Combined power (+12V)
432
Combined power (+5V)
103
Combined power (-12V)
3.6
Combined power (+5Vsb)
15
Max output current (+3.3V)
18
Max output current (+12V)
36
Max output current (+5V)
15
Max output current (-12V)
0.3
Max output current (+5Vsb)
3
Hold time
16
Efficiency
85
Power protection features
Over current
Power protection features
Over power
Power protection features
Over voltage
Power protection features
Overheating
Power protection features
Short circuit
Power protection features
Under voltage
